The multifunction beauty machine can support 6 different handpieces:
APPLICATION OF Multi function platform laser device HS-910
It is perform all your need for skin & hair treatment. The multi-application platform can distinguish 8 different type of handpiece functions automatically.
PRINCIPLE OF Multi function platform laser device HS-910
The HS-900 is a new platform treatment system with 8” display screen can be adapted 8 technologies treatment handles for various conditions. These 8 technologies adapted IPL / EPL/ RF Bi-polar / RF mono-polar / 1064+532nm Q-Switch / 1064nm Long Pulse / 1540nm Er.Glass / 2940nm Er. YAG.
Advantage of Multi function platform laser device HS-910
Medical grade 8-in-1 laser platform
With auto-detect interchangeable handpieces
2940nm Er:Yag Fractional Ablative Laser
2940nm ER: YAG laser was chosen due to its high ablation efficiency. Because of high absorption in target chromophore water at the 2940nm wavelength, the skin will be quickly heated up and instantly peeled off with very little thermal energy. The treatment features a shallow exposure depth; therefore the affected part can be healed almost instantly. Apply for Skin Resurfacing, Melasma, Wrinkles and fine lines, Wart and nevus removal ..
IPL / EPL HANDPIECE
Superior selective filters
BBR function Innovative in-motion way for facial & whole body rejuvenation and skin toning.
Smart pre-set treatment protocols for precise individual treatment.
Q-SWITCHED ND:YAG LASER HANDPIECE
The ideal choice for the treatment of pigmented lesions, skin soft peeling and unwanted tattoos. The 1064nm wavelength is best indicated for blue, black and brown tattoo pigments. The 532 KTP is most effective on red, tan, purple and orange pigments. Φ7mm beam expander tip(optional) for carbon peeling.
1540NM ER: GlASS FRACTOINAL LASER HANDPIECE
It is idea choice for skin resurfacing,surgical scar, acne scar treatment strech marks, melasma removal, deep wrinkle removal, improve skin fine lines.
1064NM LONG PULSE ND:YAG LASER HANDPIECE
It is ideal choice for treatment for permanent hair removal for all skin types, leg veins and telangiectasia vascular lesion and wrinkle removal, is suitable for all skin types. Sapphire Cooling Treatment Lens for best comfortable feeling.
RF BIPOLAR/ MONOPOLAR
It is good choice for sculpture, cellulite skin treatment, skin tightening make the pore contracted, deep wrinkle removal Improve the skin-metabolism. Each handle with 3 different size 316 stainless treatment tip (Φ18mm, Φ28mm, Φ37mm) for better facial & body treatment. 200W output power ensure high frequency wave permeates into epidermis for excellent treatment result.
Specifications of Multi function platform laser device HS-910
Handpiece | 2940nm Er:YAG fractional ablative laser |
Spot Size | 10x10mm ø6mm,ø9mm,ø1-3.5mm 7×7 pixel:8~52mJ/MTZ |
Repetition Rate | 1-7Hz |
Pulse Width | 0.2~0.4ms,1~3ms |
Energy | 9×9 pixel:5~27mJ/MTZ Beam expander:400~2600mJ Zoom lens:400~2600mJ |
Handpiece | 1540nm Er:Glass fractional laser |
Energy | 10×10 pixel:25~70mJ/MTZ 18×18 pixel:6~24mJ/MTZ |
Pulse Width | 10ms,15ms |
Handpiece | 1064nm Long Pluse Nd:YAG Laser |
Pulse Width | 10~40ms |
Repetition Rate | 1Hz |
Delay time | 5~50ms |
Energy density | ø9mm 10~100J/cm2 ø6mm 60~240J/cm2 2.2*5mm 150~500J/cm2 |
Handpiece | 1064/532nm Q-Switch Nd:YAG Laser |
Spot Size | 1-5mm |
Pulse Width | <10ns (single pluse) |
Repetition Rate | 1-10Hz |
Max.Energy | 2400mJ(ø7),4700mJ(ø6+ø7) |
Energy | 9×9 pixel:5~27mJ/MTZ Beam expander:400~2600mJ Zoom lens:400~2600mJ |
Handpiece | IPL/EPL |
Spot Size | 15*50mm |
Wavelength | 420~1200nm |
Filter | 420/510/560/610/640~1200nm,690~950nm,SHR |
IPL/EPL Energy | 1~30J/cm2 (10~60 level) |
Handpiece | Diode laser |
wavelength | 810nm |
Laser output | 800W/1200W |
Spot size | 12*18nm/12*30nm |
Energy density | 1-64J/CM2 |
Repetition rate | 1-10HZ |
Pluse width | 10-300ms |
Sapphire cooling | -4~4℃ |
