HS-298

Share To:

Picosecond laser is strict produced in accordance with ISO 13485, USA FDA and Medical CE approved

Product Description

Principle of picosecond laser

The principle of laser freckle is that the skin melanin particles will absorb specific light waves, so the use of a specific wavelength of laser can act on the melanin particles, so that it can produce a photomechanical effect: that is, when the laser treatment is used, the high-energy light can produce a high-impact shock wave, which is used to crush the large group of melanin into powder. The large group of melanin is scattered in the skin after being broken, the naked eye looks like there is no stain, and the broken melanin is easier to be metabolized by the stratum corneum and the blood circulation lymphatic cycle because of its smaller size.

HS-298插图

HS-298插图1

Picosecond laser advantages

1. Shorter time and faster speed
2, honeycomb lens can make the energy more concentrated
3, unique wavelength, remove melanin effect is good
4, not easy to damage the skin
5, don’t worry about anti-black effect

HS-298插图2

Picosecond Nd:YAG laser specifications

Model Name HS-298
Laser Type Picosecond Nd:YAG laser
Wavelength 1064nm/532nm
Beam profile Flat-top mode
Pulse width 300ps
Pulse energy 500mJ: 1064nm
250mJ: 532nm
Energy calibration External & self-restoration
Spot size 2~10mm
Repetition rate Max.10HZ
Optical delivery 7 jointed Articulated arm
Operate interface 9.7″ true color touch screen
Aiming beam Diode 655nm(red), brightness adjustable
Cooling system Advanced air & water cooling system
Power supply AC100V or 230V, 50/60HZ
Dimension 97*48*97cm (L*W*H)
Weight 150kg

HS-298插图3

HS-298插图4
